More comfort, power and driving pleasure on two wheels: with our TCU, motorcyclists can choose between automatic or manual gear changes - without using the clutch. The control unit selects the optimal shift point by synchronizing with the transmission.
Our Twin Engine Transmission Control Unit TCU for Motorcycles
The Twin Engine Transmission Control Unit TCU offers motorcyclists more comfort when changing gear, without them having to change their behavior or give up their shifting habits. It controls two brushless motors via two channels. The advantage: drivers can choose between automatic and manual gear changes, and the Speed-Shift function is also supported. The control unit always selects the optimum time for the gear change, synchronized with the transmission.
Technical Specifications
For the Twin Engine Transmission Control Unit TCU for Motorcycles
- 2 Channels to control two brushless engines
- Processor: 200 MHz Core
- Communication protocol: CAN FD
- Operating temperature: -40 °C to 85 °C
- Dimensions: 120 x 105 x 50 mm
- Weight: 350g
- Security level: ISO 26262 ASIL B
- Safety class: IP69
